A1000

Automated system for sliding doors

Passage opening

700 – 3.000 mm

Max. leaf weight

110 – 2×70 Kg

FAAC A1000 SERIES automated systems are intended for the automation of exits in compliance with European Standard EN16005; in fact they are able to meet the most strict security standards according to EN 13489-1 Pl “c”.
Thanks to its small dimensions the A1000 is suitable for every architectural environment also in case of small places
Thanks to its multiple use, A1000 is suitable for single leaf sliding doors weigthing 110 Kg or double leaves sliding doors weighing 70 + 70 Kg.

Item code	Model	Leaf	Passage opening mm	Max. leaf weight kg	Self-supporting (head section length) mm
105057PA	A1000	single	700 ÷ 3.000	110	no
105057PA	A1000	double	800 ÷ 3.000	70 + 70	no

Model	A1000
Power supply voltage	220-240 V~ – 50/60 Hz
Max. power	140 W
Standby power without accessories	3 W
Use frequency	100%
Max leaf width	60 mm
Electric motor	Motor powered at 36V with encoder
Max. accessories load	1A – 24V
Type of traction	By means of toothed belt
Opening leaf time	10 ÷ 60 cm/s (1 leaf) – 10 ÷ 140 cm/s (2 leaves)
Closing leaf time	10 ÷ 60 cm/s (1 leaf) – 10 ÷ 140 cm/s (2 leaves)
Partial opening adjustment	5% ÷ 100% of total opening
Pause time	0 – 30 s
Night pause time	0 – 240 s
Encoder	As standard
Protection sensor monitoring (EN16005)	As standard (may be excluded)
Low energy movement (EN16005)	As standard (may be excluded)
Operating ambient temperature	-20°C ÷ +55°C
Protection class	IP 23 (for internal use only)
Compliance with regulations	EN 16005; EN 13489-1 Pl “c” ; EN 13489-2; EN 60335-1; EN 60335-2; EN ISO 12100; EN 61000-6-2; EN 61000-6-3
